5,5 GrowTech - Off GridPure Sine Wave 48V

GROWTECH 5.5KW OFF GRID INVERTER - GT-MP5548

Introducing the Growtech Inverter, the ultimate combination of affordability and technology. With a 5.5KW pure sine wave output, it delivers exceptional performance and reliability. This inverter is packed with features, including a built-in 100A MPPT solar charge controller for seamless solar system integration, a smart LCD screen for intuitive settings adjustment, and communication capabilities with Lithium batteries. Additionally, it offers a convenient lithium battery activation function. The Growtech Inverter integrates effortlessly with solar systems, AC utilities, and battery power sources to ensure a continuous power supply.

Key Features:

Overload, short circuit, and deep discharge protection.
Cold start function for uninterrupted power transfer.
Maximum PV Array Open Circuit Voltage: 500V.
Lithium battery activation function.
Support for Growatt RS485 communication.
Support for USB and RS485 monitoring functions.
Optional WIFI remote monitoring for easy management.
Compatibility with generators for flexible power sourcing.

INVERTER OUTPUT
Rated Power (Main+Second Load)  - 5500VA/5500W
Parallel Capability  - NO
Surge Power - 11000VA
Waveform - Pure sine wave
AC Voltage Regulation (Batt.Mode) - 230VAC±5%(Setting)
Inverter Efficiency(Peak) - 90~93%
Transfer Time - 10ms (UPS ) / 20ms (APL)

AC INPUT
Voltage - 230VAC±5%
Selectable Voltage Range - 170~280VAC(UPS) / 90~280VAC(APL)
Frequency Range - 50Hz / 60Hz(Auto sensing)

BATTERY
Normal voltage - 48/51VDC
Floating Charge Voltage - 54VDC
Overcharge Protection - 63VDC
Lithium Activation - YES
Lithium Battery Communication - TES via RS485

SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage - 500VDC
Maximum PV Input Current - 18A
Charging Algorithm - 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power - 5500W
PV Array MPPT Voltage Range(Typ.) - 60~500VDC
Maximum Solar Charge Current - 100A
Maximum AC Charge Current - 80A
Maximum Charge Current - 100A

MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) - 438*295*105
Package Dimension (W*H*D)(mm) - 560*375*185
N.W (kg) - 9
G.W (kg) - 10

OTHER
Humidity - 5% to 95% Relative humidity (Non-condensing)
Operating Temperature - -10°C~50°C
Storage Temperature - -15°C~60°C
Warranty - 1 Year
