Solarwize BNC-1002 100AH 12VDC Lead Carbon Battery

Solarwize Africa BNC-1002 Lead Carbon Battery - 100Ah 12V

Solarwize Africa Lead Carbon Battery with AGM separator and multi-element patent rare earth alloy. Up to 60% DOD and up to 2500 Cycles. Can be used in data centers, telecommunication, ups, solar and wind energy. 100AH 12VDC Lead Carbon Battery LIMITED WARRANTY, please refer to user manual and usage terms.

Nominal Voltage - 12V

Rated Capacity (20HR) - 100Ah

Rated Capacity (10AH) - 80Ah

Internal Resistance - 6.5mΩ@25℃(77℉)

Short Circuit Current - 960A (5Seconds)

Operating Temperature Range

Discharge: -15°C~50°C

Charge: 0 ~ 40°C

Storage: -15°C~40°C

Optimum: 25±3℃

Physical Specifications

Material : ABS UL94-HB (ABS UL94-V0)

Terminal Type: I7

Length: 330mm

Width: 171mm

Height: 214mm

Weight: 30.5kg

Charging Specification

Cut-off Voltage: 11.8V

Floating Charge Voltage: 13.5V

Bulk Charge Voltage: 14.4V

Max Charge Cureent: 30A

Recommended Charge Current: 20A

Short Circuit (MAX) Current: 960A 5Seconds

Discharge Specification

Current: 1 - 80A

Safe Temperature Range: -10°C TO 40°C
